4.
Using a thin, non-conductive tool, press on the back of the keyboard through the release access
hole until the keyboard disengages from the computer.
NOTE: The keyboard icon indicates the location of the keyboard release access hole.
5. Turn the computer right-side up with the front toward you.
6. Lift the rear edge of the keyboard (1), and then swing the keyboard (2) up and forward until it
rests upside down on the palm rest.
ENWW
Component replacement procedures
55
