Fan and heat sink
NOTE: The fan and heat sink spare part kits include replacement thermal material.
Description Spare part number
Fan 680551-001
Heat sink for use only with computer models equipped with UMA video memory for BGA-based
systems
711471-001
Heat sink for use only with computer models equipped with UMA video memory 680549-001
Heat sink for use only with computer models equipped with switchable discrete video memory for
BGA-based systems
711472-001
Heat sink for use only with computer models equipped with switchable discrete video memory 680550-001
NOTE: To properly ventilate the computer, allow at least 7.6 cm (3 in) of clearance on the left side of
the computer. The computer uses an electric fan for ventilation. The fan is controlled by a temperature
sensor and is designed to turn on automatically when high temperature conditions exist. These
conditions are affected by high external temperatures, system power consumption, power
management/battery conservation configurations, battery fast charging, and software requirements.
Exhaust air is displaced through the ventilation grill located on the left side of the computer.
Before removing the fan and heat sink, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 41).
5. Remove the service door (see
Service door on page 42).
6. Remove the optical drive (see
Optical drive on page 43).
7. Remove the hard drive (see
Hard drive on page 45)
8.
Remove the keyboard (see
Keyboard on page 52).
9. Remove the top cover (see
Top cover on page 57).
10. Remove the system board (see
System board on page 75).
