Remove the top cover:
1. Disconnect these cables from the system board:
(1) Power button board ZIF cable
(2) Speaker cable
(3) TouchPad button board ZIF cable
2. Remove the following screws under the keyboard:
(1) Five PM 2.5 x 4.0
(2) One PM 2.5 x 6.5
NOTE: This screw (2) also secures the speaker underneath the top cover.
3. Close the computer.
58 Chapter 4 Removal and replacement procedures ENWW
