5. Separate the display from the computer (2).
6. If it is necessary to replace display assembly subcomponents, rst remove the bezel:
a. Insert a non-marking, non-conductive tool into the seam at the bottom of the bezel and pull to
release the bezel from the display (1).
b. Release the top edge of the display bezel (2) from the display assembly.
IMPORTANT: Be careful not to bend or break the narrow sections of the bezel when removing.
c. Release the left and right edges of the display bezel (3) from the display assembly.
d. Release the bottom edge of the display bezel (4) from the display assembly.
50 Chapter 6 Removal and replacement procedures for authorized service provider parts
