Battery
Description Spare part number
4-cell, 48-Whr, 3.2-Ah Li-ion battery 800050-001
4-cell, 41-Whr, 2.8-Ah Li-ion battery 800049-001
Before disassembling the computer, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
To remove the battery:
1. Position the computer upside down on a at surface.
2. Slide the battery lock latch (1), and then slide the battery release latch (2) to release the battery.
3. Rotate the battery upward (3), and then remove the battery from the computer (4).
34 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
