HP Pavilion HDX - Phillips PM2.5×11.0 screw

Where used: 2 captive screws (secured by C-clips) that secure the hard drives to the computer
Phillips PM3.0×4.0 screw
Color Quantity Length Thread Head diameter
Silver 8 4.0 mm 3.0 mm 5.0 mm
Where used: 8 screws that secure the hard drive brackets to the two hard drives
102 Chapter 7 Screw listing
