20.1-inch, WUXGA display specifications
Metric U.S.
Dimensions
Height
27.40 cm 10.79 in
Width 43.55 cm 17.15 in
Diagonal 51.10 cm 20.11 in
Number of colors
Up to 16.8 million
Contrast ratio
200:1 (typical)
Brightness
180 nits (typical)
Pixel resolution
Pitch
0.172 × 0.172 mm
Format 1920 × 1200
Configuration RGB vertical stripe
Backlight
CCFT
Character display
80 × 25
Total power consumption
6.0 W
Viewing angle
+/-65° horizontal, +/-50° vertical (typical)
20.1-inch WSXGA+ display specifications
Metric U.S.
Dimensions
Height
27.40 cm 10.79 in
Width 43.55 cm 17.15 in
Diagonal 51.10 cm 20.11 in
Number of colors
Up to 16.8 million
Contrast ratio
200:1
Brightness
180 nits typical
Pitch resolution
Pitch
0.172 × 0.172 mm
Format 1680 × 1050
Configuration RGB vertical stripe
Backlight
CCFT
Character display
80 × 25
88 Chapter 6 Specifications
