3. Reattach the cables to the bottom end of the
hard disk drive.
4. Set the hard drive cage down into the bay,
aligning the tabs on the bottom of the cage with
the slots on the chassis.
5. Once the cage is set on the slots (1), press down
and slide the cage toward the bottom of the
computer until it stops (2), ensuring that the three
screw holes are aligned.
6. Using a flathead or Torx screwdriver, secure the
hard disk drive cage in place.
6 Upgrading and Servicing Guide Features may vary by model.
