7. Insert the retaining bar in the back of the
computer (1), and then align the screw holes at
the front of the computer (2).
8. Insert the two screws, securing the retaining bar
in place.
9. Place the computer in an upright position.
10. Insert the three tabs on the bezel door into the
slots on the computer, and then close the bezel
door until it locks in place.
11. Install the side panel on the side of the
computer, and then slide it toward the front of
the computer.
NOTE: Make sure the panel is flush with the
computer. Failure to do so might cause the panel
to bend slightly outward and not close securely.
Features may vary by model.
Removing and Replacing a Hard Disk Drive
7
