HP Pavilion m6 User Manual

7.
Disconnect the display panel cable (2) from the system board.
8.
Release the wireless antenna cables from the clips (3) and routing channel built into the
base enclosure.
CAUTION: Support the display assembly when removing the following screws. Failure to
support the display assembly can result in damage to the display assembly and other computer
components.
9. Remove the four Phillips PM2.5×5.0 screws (1) that secure the display assembly to the
base enclosure.
94 Chapter 4 Removal and replacement procedures

HP Pavilion m6 Specifications

General

Processor	Intel Core i7
RAM	Up to 8GB DDR3
Storage	Up to 1TB HDD or SSD options
Display	15.6-inch HD or Full HD
Graphics	Intel HD Graphics 4000, AMD Radeon HD 7670M
Operating System	Windows 8
Battery	6-cell Lithium-Ion battery
Wireless	802.11b/g/n, Bluetooth
Audio	Beats Audio
Webcam	HD webcam
Ports	USB 3.0, USB 2.0, HDMI, VGA, Ethernet, headphone/microphone combo jack, multi-format card reader
