HP Pavilion m6 User Manual

Top cover
NOTE: The top cover spare part kit includes a TouchPad.
Description Spare part number
In midnight black finish 686931-001
In natural silver finish 690232-001
Before removing the top cover, follow these steps:
1.
Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 48), and then remove the following components:
a.
Hard drive (see
Hard drive on page 49)
b.
Optical drive (see
Optical drive on page 53)
c. Keyboard (see
Keyboard on page 57)
NOTE: When replacing the top cover, be sure to remove the following components from the defective
top cover and install them on the replacement top cover:
●
Power button board (see
Power button board on page 70)
●
Fingerprint reader board (see
Fingerprint reader board on page 72)
●
TouchPad button board (see
TouchPad button board on page 74)
66 Chapter 4 Removal and replacement procedures

HP Pavilion m6 Specifications

General

Processor	Intel Core i7
RAM	Up to 8GB DDR3
Storage	Up to 1TB HDD or SSD options
Display	15.6-inch HD or Full HD
Graphics	Intel HD Graphics 4000, AMD Radeon HD 7670M
Operating System	Windows 8
Battery	6-cell Lithium-Ion battery
Wireless	802.11b/g/n, Bluetooth
Audio	Beats Audio
Webcam	HD webcam
Ports	USB 3.0, USB 2.0, HDMI, VGA, Ethernet, headphone/microphone combo jack, multi-format card reader
