4. Remove the four Phillips screws for the display panel.
5. Move the panel toward the keyboard (1).
NOTE: Support the display panel as you lean the panel forward.
6. Release the adhesive support strip (2) that secures the display panel cable connector to
the display panel.
7. Disconnect the display panel cable (3) from the display panel, and then remove the panel (4).
Reverse this procedure to replace the panel.
36 Chapter 4 Removal and replacement procedures
