mSATA solid-state drive
Description Spare part number
mSATA solid-state drive, 32 GB drive (for use with computers with Intel Core processors, not
supported on Ubuntu Linux)
698524-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement.
Before removing the mSATA solid state drive, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 33).
5. Remove the keyboard (see
Keyboard on page 37).
6. Remove the top cover (see
Top cover on page 40).
7. Remove the hard drive (see
Hard drive on page 44).
8. Remove the USB board (see
USB board/Audio jack on page 47).
9. Remove the WLAN (see
WLAN module on page 48).
10. Remove the system board (see
System board on page 51).
Remove the mSATA drive:
1. Turn the system board upside down, with the front toward you.
Component replacement procedures 59
