HP Pavilion zv5000 - Notebook PC User Manual

4–18 Hardware Guide
Drives
Connecting an Optional Digital Drive to the
USB Port
The optional Digital Drive can be connected to the USB port with
the USB cable either retracted or extended.
To connect the Digital Drive with the USB cable retracted:
1. Ensure that you have installed an SD Memory Card into
the Digital Drive.
2. Insert the USB connector on the Digital Drive into the
USB port on your notebook.
Connecting the Digital Drive to the USB port

HP Pavilion zv5000 - Notebook PC Specifications

General

Processor	Intel Pentium 4 or AMD Athlon XP
Storage	40GB to 80GB HDD
Operating System	Windows XP Home or Professional
Wireless	802.11b/g WLAN
RAM	Up to 2GB DDR SDRAM
Optical Drive	DVD/CD-RW Combo or DVD+/-RW
Weight	6.8 lbs (3.1 kg)
Ports	3x USB 2.0, VGA, S-Video, Ethernet, Modem, Headphone, Microphone, IEEE 1394, PCMCIA
Networking	10/100 Ethernet, 56k Modem
Battery	6-cell Lithium-Ion
Display	15.4-inch WXGA (1280x800)
