Bottom
Component Description
(1) Vents (4) Enable airflow to cool internal components.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal
for the internal fan to cycle on and off during routine
operation.
(2)
Battery lock Locks the battery in the battery bay.
(3) Battery bay Holds the battery.
(4)
Battery release latch Releases the battery.
Bottom 13
