Display assembly, non-touch
Description Spare part number
Raw display panel (39.6-cm [15.6-in]; includes Mylar screw covers)
BrightView, HD, flat 809371-001
AntiGlare, FHD, slim 809372-001
Antennas (include Mylar screw covers) 809008-001
Display bezel 809027-001
Display cable (includes Mylar screw covers)
For use in non-touch displays 809028-001
For use in TOP (Touch On Panel) displays 809342-001
Display enclosure (includes Mylar screw covers)
For use in non-touch models:
●
Red models 809011-001
●
White models 809010-001
●
Blue models 809012-001
●
Silver models 809009-001
●
Purple models 809014-001
●
Pink models 809013-001
●
Black models 809343-001
For use in TOP (touch on panel) models:
●
Black models 818657-001
●
Red models 818653-001
●
White models 817836-001
●
Silver models 817835-001
●
Blue models 818654-001
●
Purple models 818656-001
●
Pink models 818655-001
Hinges (left and right) (include Mylar screw covers) 809030-001
Webcam/microphone module 806758-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
56 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
