Item Component Spare part
number
For use in models with a backlit keyboard:
●
For use in French Canada 809032-DB1
●
For use in Saudi Arabia 809032-171
●
For use in Turkey 809032-141
●
For use in the United States 809032-001
(3) Optical Drive Cable Kit 811199-001
(4) Touchpad 813987-001
(5) Power button board (includes cable) 809033-001
(6) Hard drive (does not include bracket):
NOTE: The hard drive bracket and connector are available using spare part number 809296-001.
2-TB, 5400-rpm, 2.5-inch 801808-005
1-TB, 5400-rpm, 2.5-inch, hybrid 8 GB SSD 731999-005
1-TB, 5400-rpm, 2.5-inch 778192-005
750 GB, 5400 rpm hard drive, 2.5 inch 778190-005
500-GB, 5400-rpm, 7 mm 778186-005
(7) USB board (includes cable) 809409-001
(8) System board (includes replacement thermal materials)
All system boards use the following part numbers:
xxxxxx-001: Without the Windows operating system
xxxxxx-501: Windows 8.1 Standard
xxxxxx-601: Windows 8.1 Professional
For use in models with 2 GB of discrete graphics memory:
●
AMD A10-8700P processor 809408-xxx
●
AMD A8-7410 processor 809407-xxx
●
AMD A6-6310 processor 809339-xxx
For use in models with UMA graphics memory:
●
AMD A10-8700P processor 809338-xxx
●
AMD A8-7410 processor 809337-xxx
●
AMD A6-6310 processor 809336-xxx
●
AMD A4-6210 processor 809335-xxx
(9) Fan 806747-001
(10) Speakers (includes left and right speakers and cable) 809037-001
(11) WLAN module
Intel Dual Band Wireless-AC 7265 802.11 ac 2x2 WiFi + BT 4.0 Combo Adapter (non vPRO) 784644-005
Computer major components 17
