Connector Description Illustration Type
Three
connectors
Your PC model may include
three sound connectors. You
can connect up to a 5.1 audio
system to the PC. If you want to
connect multichannel audio,
follow the instructions carefully.
3
Six
connectors
Your PC model may include six
sound connectors on the back
of your PC. You can connect
up to a 7.1 audio system to
the PC.
6
Sound card
connector
Your PC may include a sound
card. You can connect up to a
5.1 audio system (7.1 audio
system for select models) or
digital speakers to the sound
card on the PC.
See below. S
NOTE:
• Type 3 is three connectors
• Type 6 is six connectors
• Type S is a sound card connector
