52 Getting Started Guide
2-slot memory card reader (select models only)
Card Insert Into 2-slot reader
Secure Digital (SD)
Memory Card
Label up
(gold connector fingers down)
F (Upper)
MultiMediaCard (MMC) Label up
(gold connector fingers down)
F (Upper)
Memory Stick (MS)
Memory Card
Label up
(gold connector fingers down)
F (Upper)
Memory Stick (MS-Pro)
Memory Card
Label up
(gold connector fingers down)
F (Upper)
SmartMedia (SM) Memory Card Label down
(gold connector fingers up)
F (Upper)
xD media Label up
(gold connector fingers down)
F (Upper)
IBM Microdrive disk drive Receptacle edge (holes)
(label up)
G (Lower)
CompactFlash Type I media Receptacle edge (holes)
(label up)
G (Lower)
CompactFlash Type II media Receptacle edge (holes)
(label up)
G (Lower)
NOTE:
Do not use SM and xD media in the memory card reader at the same time.
Only the first one inserted is recognized by the memory card reader.
A
F
G
A A
ctivity
l
ig
h
t
F Upper slot
G Lower slot
xD
