System Board Drive Connections – Model 3505
System Board Connector System Board Label Color
SATA1 SATA1 dark blue
SATA2 SATA2 white
SATA3 SATA3 light blue
SATA4 SATA4 orange
Media Card Reader CARD_READER (3505) black
68 Chapter 7 Removal and Replacement Procedures – Microtower Chassis
