6. Slide the power supply toward the front of the computer (2), then lift the power supply out of the
computer (3).
To install the power supply, reverse the removal procedure.
System Board
NOTE: All system board spare part kits include replacement thermal material.
Description Spare part number
System board for use in 3400 models (Intel) 660281-001
System board for use in 3405 models (AMD) 660155-001
System board for use in 3410 models (Intel) 665223-001
System board for use in 3500 models (Intel) 687577-001
System board for use in 3500 models (Intel) and Windows 8 with no Digital Product Key (DPK) 701413-001
System board for use in 3500 models (Intel) and Windows 8 Standard 701413-501
System board for use in 3500 models (Intel) and Windows 8 Professional 701413-601
System board for use in 3505 models (AMD) 687578-001
System board for use in 3505 models (AMD) and Windows 8 with no Digital Product Key (DPK) 701022-001
System board for use in 3505 models (AMD) and Windows 8 Standard 701022-501
System board for use in 3505 models (AMD) and Windows 8 Professional 701022-601
System board for use in 3515 models (AMD) and Windows 8 with no Digital Product Key (DPK) 700846-001
System board for use in 3515 models (AMD) and Windows 8 Standard 700846-501
System board for use in 3515 models (AMD) and Windows 8 Professional 700846-601
System Board 83
