HP ProBook 4310s User Manual

Product description
Maintenance and Service Guide 1–5
Audio 2 stereo speakers with enclosures
Azalea ADI1984 CODEC with
digital equalization
Headphone jack
Microphone jack
999
Webcam Integrated 2-megapixel camera
with fixed focus
999
Modem High-speed 56K data/fax modem
Supports no-modem option
Modem module cable not included
999
Ethernet Marvell 88E8072-B1 10/100/1000
network interface card (NIC)
S3/S4/S5 wake on LAN
(AC mode only)
Ethernet cable not included
999
Wireless Integrated wireless local-area
network (WLAN) options via
Mini PCI module:
■ Broadcom 4322AGN
802.11b/g/n WLAN module
■ Broadcom 4312G 802.11b/g
WLAN module
■ Intel WiFi Link 5100
802.11b/g/n WLAN module
■ Intel WiFi Link 5100 802.11b/g
WLAN module
Supports no-WLAN option
2 WLAN antennas built into the
display assembly
999
Integrated wireless wide-area
network (WWAN) options via
Mini PCI module:
■ High-speed packet access
(HSPA), evolution-data
optimized (EV-DO) WWAN
module
■ Telecom EV-DO CT1 WWAN
module
■ Telecom EV-DO CT2 WWAN
module
WWAN security provided by
subscriber identity module (SIM),
user-accessible behind battery
2 WWAN antennas (worldwide,
5-band) built into the
display assembly
Does not support WWAN
aftermarket option
999
Integrated wireless personal area
network (WPAN) options via
Bluetooth® module
999
(Continued)
Category Description PM45 chipset GM45 chipset GL40 chipset

HP ProBook 4310s Specifications

General

Processor	Intel Core 2 Duo
Processor Speed	2.1 GHz
Graphics	Intel GMA 4500MHD
Battery	6-cell Lithium-Ion
Display	13.3-inch, 1366 x 768 pixels
Storage	250 GB HDD
Operating System	Windows Vista
Weight	2.0 kg (4.4 lbs)
Optical Drive	DVD+/-RW SuperMulti DL
Wireless	802.11a/b/g/n
