6. Remove the screws from the battery area.
7. Turn the computer display-side up, and open the computer as far as possible.
NOTE: Do not use excessive force to open the computer beyond the limits of the display
hinges. Forcing extension beyond these limits will cause damage to the display.
8. Slide the switch cover straight back toward the display (1), and then remove the switch cover (2).
64 Chapter 14 Hardware upgrades
