Item Description Spare part number
(1) Display panel, 33.8-cm (13.3-inch) HD, anti-glare 684251-001
(2) Keyboard (includes cable)
NOTE: For a detailed list of available keyboards, see
Sequential part number listing
on page 30.
For use in models without Windows 8 684252-xxx
For use in Windows 8 models 701974-xxx
(3) Top cover (includes touchpad)
For use in models with a fingerprint reader 684243-001
For use in models without a fingerprint reader 684244-001
(4) Audio board (includes cable) 684245-001
(5) RTC battery 684248-001
(6) Function board/Power button board (includes cables) 684240-001
(7) Fingerprint reader assembly (includes cable and bracket) 683862-001
(8) System board (includes replacement thermal material)
For use in models without Windows 8 models:
●
Discrete graphics 683855-001
●
UMA graphics 683856-001
● UMA graphics in Japan 696335-001
For use in Windows 8 models:
●
Discrete graphics and Windows 8 Standard 683855-501
● Discrete graphics and Windows 8 Professional 683855-601
●
UMA graphics and Windows 8 Standard 683856-501
●
UMA graphics and Windows 8 Professional 683856-601
● Discrete graphics and Windows 8 Standard in Japan 696335-501
●
UMA graphics and Windows 8 Professional in Japan 696335-601
(9) Speaker assembly 684242-001
(10) Power connector cable (includes bracket and screws) 683859-001
(11) Battery, Li-ion, 6-cell, 51 WHr, 2.55 Ah 669831-001
(12) Base enclosure 683857-001
(13) Hard drive
500-GB, 5400-rpm 683802-001
320-GB, 7200-rpm 634862-001
320-GB, 5400-rpm 645193-001
128-GB solid-state drive 684253-001
24 Chapter 3 Illustrated parts catalog
