Bottom
NOTE: Your computer may look slightly different from the illustration in this section.
Component Description
(1)
Battery and service door release latches
●
Releases the battery from the battery bay by sliding
the release latches one time.
●
When the battery has been removed from the battery
bay, releases the service door from the computer by
sliding the release latches a second time.
(2) Battery bay Holds the battery.
Bottom 17
