8. Insert a new memory module:
CAUTION: To prevent damage to the memory module, hold the memory module by the edges
only. Do not touch the components on the memory module.
a. Align the notched edge (1) of the memory module with the tab in the memory module slot.
b. With the memory module at a 45-degree angle from the surface of the memory module
compartment, press the module (2) into the memory module slot until it is seated.
c. Gently press the memory module (3) down, applying pressure to both the left and right
edges of the memory module, until the retention clips snap into place.
CAUTION: To prevent damage to the memory module, be sure that you do not bend the
memory module.
9. Replace the service door (see Removing or replacing the service door on page 31).
10. Replace the security screw, if desired (see
Using the optional security screw on page 30).
11. Replace the battery (see
Inserting or removing the battery on page 29).
12. Turn the computer right-side up, and then reconnect AC power and external devices to the
computer.
13. Turn on the computer.
Adding or replacing memory modules 37
