Table 3-3 Cable Kit components and their descriptions (continued)
Item Description Spare part number
(3) Touchpad cable
(4) Fingerprint sensor cable
Bracket Kit
Table 3-4 Bracket Kit components and their descriptions
Item Description Spare part number
Bracket Kit, includes the following parts: L77264-001
(1) Fingerprint sensor bracket
(2) USB Type-C port bracket
(3) RJ-45 (network) jack bracket
Fingerprint sensor insert (for use in models without a ngerprint sensor; not illustrated)
Bracket Kit 21
