HP ProBook 445 G7 Service Manual

1 Product description
Table 1-1 Product components and their descriptions
Category Description
Product Name HP ProBook 445 G7 Notebook PC
Processors AMD® Ryzen™ Mobile Processor (15 W)
Ryzen 7 PRO 4750U, 1.7 GHz/4.2 GHz, eight cores, 8 MB L3 cache; 4 MB L2 cache; AMD Radeon™ Graphics
Ryzen 7 4700U, 2.0 GHz/4.2 GHz, eight cores, 8 MB L3 cache; 4 MB L2 cache; AMD Radeon Graphics
Ryzen 5 PRO 4650U, 2.1 GHz/4.0 GHz, eight cores, 8 MB L3 cache; 4 MB L2 cache; AMD Radeon Graphics
Ryzen 5 4500U, 2.375 GHz/4.0 GHz, six cores, 8 MB L3 cache; 3 MB L2 cache; AMD Radeon Graphics
Ryzen 3 4300U, 2.7 GHz/3.8 GHz, four cores, 4 MB L3 cache; 2 MB L2 cache; AMD Radeon Graphics
Graphics Supports HD decode, DX12, HDMI 1.4b up to 4 K @ 30 Hz
AMD Radeon Graphics
Supports 4 independent displays when on the HP USB-C Dock G4; Max resolution = 4 K @ 30 Hz
(DisplayPort 1) or 4 K @ 30 Hz (DisplayPort 2)
Supports 4 independent displays when on the HP Thunderbolt™ Dock 120 W G2; Max resolution = 4 K @ 30
Hz (DisplayPort 1) or 4 K @ 30 Hz (DisplayPort 2)
Supports 4 independent displays when on the HP USB-C Mini Dock ; Max resolution = 4 K @ 30 Hz (HDMI) or
1920 × 1080 @ 60 Hz (VGA)
Supports 4 independent displays when on the HP USB-C Universal Dock; Max resolution = 4 K @ 30 Hz
(DisplayPort 1) or 4 K @ 30 Hz (DisplayPort 2)
Panel 35.6 cm (14.0 in), LED backlight, antiglare, nontouch
High denition (HD) (1366 × 768), SVA, 45% CG, eDP, slim, 220 nits
HD, SVA, 45% CG, eDP, slim, 220 nits, with HD camera
HD, SVA, 45% CG, eDP, slim, 220 nits, with HD + IR camera
Full high denition (FHD) (1920 × 1080), UWVA, 45% CG, eDP, slim, 250 nits
FHD, UWVA, 45% CG, eDP, slim, 250 nits, with HD camera
FHD, UWVA, 45% CG, eDP, slim, 250 nits, with HD + IR camera
FHD, UWVA, 72% CG, eDP, slim, 400 nits, with HD camera
FHD, UWVA, 72% CG, eDP + PSR, at, 1000 nits, privacy, with HD camera
Memory Two customer-accessible memory module slots supporting up to 16 GB of RAM
Supports dual-channel memory
PC4-3200, DDR4 SODIMMs
Supports the following congurations:
● 32 GB (16 × 2)
1

HP ProBook 445 G7 Specifications

General

Operating System	Windows 10 Pro
Ports	2 x USB 3.1, 1 x USB-C, 1 x HDMI, 1 x RJ-45, 1 x headphone/microphone combo
Processor	AMD Ryzen 5 4500U
Display	14-inch, 1920 x 1080 pixels
RAM	Up to 32GB DDR4
Storage	Up to 1TB PCIe NVMe SSD
Graphics	AMD Radeon Graphics
Weight	1.6 kg
Battery	3-cell, 45 Wh Li-ion
Wireless	Wi-Fi 6 (802.11ax), Bluetooth 5
