5. Rotate the top of the keyboard upward (1), and then lift the keyboard up at an angle (2) to disengage the
tabs at the bottom of the keyboard.
NOTE: A cable connects the bottom of the keyboard to the system board. Make sure not to
prematurely pull the keyboard cable out of the system board connector.
6. Rotate the keyboard until it rests on the palm rest (1).
Component replacement procedures 51
