System board

NOTE: All system board spare part kits include replacement thermal material.

All system boards use the following part numbers:

xxxxxx-001: Windows 7 or non-Windows operating systems

xxxxxx-501: Windows 8.1 Standard operating system

xxxxxx-601: Windows 8.1 or Windows 10 operating system

Description Spare part number

System boards for use in models with Intel processors:

Intel i7-5500U processor; 2-GB discrete graphics memory 799562-xxx

Intel i7-5500U processor; UMA graphics memory; no WWAN models 799553-xxx

Intel i7-5500U processor; UMA graphics memory; WWAN models 799555-xxx

Intel i5-5200U processor; 2-GB discrete graphics memory 799561-xxx

Intel i5-5200U processor; 1-GB discrete graphics memory 799558-xxx

Intel i5-5200U processor; UMA graphics memory; no WWAN models 779552-xxx

Intel i5-5200U processor; UMA graphics memory; WWAN models 799554-xxx

Intel i3-5020U processor; 2-GB discrete graphics memory 824133-xxx

Intel i3-5020U processor; 1-GB discrete graphics memory 824132-xxx

Intel i3-5020U processor; UMA graphics memory; no WWAN models 824129-xxx

Intel i3-5010U processor; 2-GB discrete graphics memory 799560-xxx

Intel i3-5010U processor; 1-GB discrete graphics memory 799557-xxx

Intel i3-5010U processor; UMA graphics memory; no WWAN models 799551-xxx

Intel i3-5005U processor; 2-GB discrete graphics memory 799559-xxx

Intel i3-5005U processor; 1-GB discrete graphics memory 779556-xxx

Intel i3-5005U processor; UMA graphics memory; no WWAN models 799550-xxx

Intel i7-4510U processor; 2-GB discrete graphics memory 768145-xxx

Intel i7-4510U processor; UMA graphics memory; non-WWAN models 768148-xxx

Intel i7-4510U processor; UMA graphics memory, WWAN models 784653-xxx

Intel i5-4210U processor; 2-GB discrete graphics memory 768143-xxx

Intel i5-4210U processor; 1-GB discrete graphics memory 768142-xxx

Intel i5-4210U processor; UMA graphics memory; WWAN models 784652-xxx

Intel i3-4030U processor; 2-GB discrete graphics memory 782950-xxx

Intel i3-4030U processor; UMA graphics memory 782952-xxx

Intel i3-4005U processor; UMA graphics memory 782951-xxx

Intel i5-4210U processor; UMA graphics memory 768146-xxx

78 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
