3. Remove the 11 Torx T8M2.5×3.0 screws that secure the top cover to the computer.
4. Position the computer upright and open it as far as possible.
5. Disconnect the following cables from the system board:
●
(1): Card reader board cable
●
(2): Power button board cable
●
(3): Function board cable
●
(4): Speaker cable
●
(5): USB board cable
6. Remove the 4 Torx T8M2.5×6.0 screws (6) from the top of the computer.
7. Pry the top cover o the computer to disengage it.
NOTE: Begin by attempting to pry the top cover loose near the optical drive.
Component replacement procedures 59
