Bottom
NOTE: Refer to the illustration that most closely matches your computer.
Component Description
(1) Vents (2) Enable airow to cool internal components.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal
for the internal fan to cycle on and o during routine
operation.
(2) Service door Provides access to the hard drive bay and the memory
module slots.
(3) Battery release latches (2) Release the battery.
(4) Service door Provides access to the wireless LAN (WLAN) module slot,
the WWAN module slot, and SIM slot.
Bottom 23
