14. If you need to remove the WWAN antennas and cables, remove the cables (1) from the inside of the
display rear cover (2), and then peel the antennas o the cover (3). The WWAN antennas and cables are
available as spare part number N03221-001.
Display rear covers are available as the following spare part numbers:
N01919-001: Models with a 250 nit panel
N01918-001: Models with a 400 nit panel
N01920-001: Models with WWAN
Reverse this procedure to reassemble and replace the display assembly.
Top cover with keyboard
The top cover with keyboard remains after removing all other spare parts from the computer. In this section,
the rst table provides the main spare part number for the top cover/keyboards. The second table provides
the country codes.
Table 6-11
Top cover with keyboard descriptions and part numbers
Description Spare part number
Top cover with keyboard, backlit N01933-001
Top cover with keyboard, not backlit N01934-001
Table 6-12 Spare part country codes
For use in country or region Spare part
number
For use in country or region Spare part
number
For use in country or region Spare part
number
Belgium -A41 Hungary -211 Saudi Arabia -171
Brazil -201 Iceland -DD1 Slovenia -BA1
Bulgaria -261 India -D61 South Korea -AD1
70 Chapter 6Removal and replacement procedures for authorized service provider parts
