Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
(14) WLAN module
Intel Wi-Fi 6 AX200 + Bluetooth 5 (non-vPro) L35282-002
Intel Wireless-AC 9260 802.11ac 2 × 2 Wi-Fi + Bluetooth® 5.1 L16647-002
Realtek RTL8822BE 802.11ac/abgn 2 × 2 + Bluetooth 5 (MU-MIMO supported) L44796-002
(15) Fingerprint reader (includes conductive tape)
NOTE: The ngerprint reader cable is available in the Cable Kit as spare part number
M21713-001. The ngerprint reader bracket is available in the Bracket Kit as spare part number
M21715-001.
M21724-001
Memory modules (DDR4, PC-3200; not illustrated)
16 GB L67710-002
8 GB L46598-002
4 GB L83673-002
Display assembly subcomponents
To identify the display assembly subcomponents, use this illustration and table.
20 Chapter 3 Illustrated parts catalog
