Item Description Spare part number
(1) Display panel assembly, 35.6-cm (14.0-inch)
Displays are ONLY spared at the subcomponent level. For more information about display
components, see Display components on page 19.
(2) Keyboard (includes cable)
NOTE: For a detailed list of keyboard country codes, see Keyboard on page 41.
No backlight 827028-xxx
Backlit 827029-xxx
(3) Power button board 905754-001
(4) Top cover (includes touchpad assembly) 905996-001
(5) Function board 910959-001
(6) Fingerprint reader assembly (includes cable) 906003-001
(7) Speaker assembly 906004-001
(8) Battery, Li-ion (4-cell, 48 WHr, 4.21 Ah) 851610-855
(9) Fan 905774-001
(10) USB/audio board 905755-001
(11) Optical drive cable and connector
The optical drive connector cable is included in the Cable Kit.
906000-001
(12) Power connector cable 828949-007
(13) System board (includes replacement thermal material)
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating system
xxxxxx-601: Windows 10 operating system
Intel Core i7-7500U processor; 2-GB discrete graphics memory 907715-xxx
Intel Core i5-7200U processor; 2-GB discrete graphics memory 907714-xxx
Intel Core i3-7100U processor; 2-GB discrete graphics memory 907713-xxx
(14) Heat sink assembly (for discrete graphics; includes replacement thermal material) 907364-001
(15) RTC battery not spared
(16) Base enclosure 905995-001
(17) WLAN module
Realtek RTL8723BE-VB 802.11b/g/n 1x1 Wi-Fi + Bluetooth 4.0 combination WLAN adapter 843338-001
Intel Dual Band Wireless-AC 3168 802.11ac, Dual Band, 1×1 Wi-Fi + Bluetooth 4.0 852511-001
(18) Memory modules (PC4-17000)
8-GB 862398-850
4-GB 862397-850
(19) Solid-state drive, M.2
16 Chapter 3 Illustrated parts catalog
