HP ProBook 5330m User Manual

Item Description Spare part number
(4) Top cover with fingerprint reader 651761-001
(5) Power button board (includes cable) 650392-001
(6) Activity button board (includes cable) 650393-001
(7) Audio board (includes cable) 650394-001
(8) Power connector bracket (included with the power connector cable)
(9) RTC battery 650398-001
(10) Power connector cable
NOTE: The power connector cable is included in the Cable Kit, spare part number
650369-001. See
Cable Kit on page 23 for more Cable Kit spare part information.
(11) System board (includes processor and replacement thermal material)
● Includes Intel Core i3-2310M, Dual-Core, 2.10 GHz, 3 MB L3 cache, 4 threads (35 W)—
for all countries except Russia and the People's Republic of China
650402-001
● Includes Intel Core i5-2520M, Dual-Core, 2.50 GHz (Turbo up to 3.20 GHz), 3 MB L3
cache, 4 threads (35 W)—for all countries except Russia and the People's Republic of
China
650403-001
●
Includes Intel Core i3-2310M, Dual-Core, 2.10 GHz, 3 MB L3 cache, 4 threads (35 W)—
for Russia and the People's Republic of China only
656796-001
●
Includes Intel Core i5-2520M, Dual-Core, 2.50 GHz (Turbo up to 3.20 GHz), 3 MB L3
cache, 4 threads (35 W)—for Russia and the People's Republic of China only
656797-001
(12) Heat sink 650372-001
(13) Speakers 650400-001
(14) Base enclosure 650367-001
(15) SD Card blank
NOTE: The SD Card blank is included in the Plastics Kit, spare part number 650395-001.
See
Plastics Kit on page 22 for more Plastics Kit spare part information.
(16) Bluetooth module (select models only)
NOTE: The Bluetooth module spare part kit does not include a Bluetooth module cable.
The Bluetooth module cable is included in the Cable Kit, spare part number 650369-001. See
Cable Kit on page 23 for more Cable Kit spare part information.
537921-001
(17) Battery (4-cell, 41 Wh, 2.8 Ah, Li-on) 635146-001
(18) Fan plate
NOTE: The fan plate is included with the fan kit, spare part number 650371-001.
(19) SATA 6.35 cm (2.50 in) hard drive
NOTE: The hard drive bracket is included in the Hard Drive Hardware Kit, spare part number 650373-001.
9.5 mm hard drives
● 500 GB, 7200-rpm 634925-001
●
320 GB, 7200-rpm, Self Encrypting 626978-001
●
320 GB, 7200-rpm 641672-001
● 250 GB, 7200-rpm 635225-001
Computer major components 19

HP ProBook 5330m Specifications

General

Bus type	DMI
Stepping	J1
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
System bus rate	5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-2300 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	21
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM67 Express
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	-
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Display diagonal	13.3 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Power supply type	AC/DC
Intel segment tagging	Enterprise
Operating temperature (T-T)	41 - 95 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Memory slots	1x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Memory slots (available)	0
Pointing device	Touchpad
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cable lock slot type	Kensington
Battery capacity	41 Wh
Battery life (max)	5.5 h
AC adapter power	65 W
Sustainability certificates	EPEAT Gold, ENERGY STAR
Product color	Black, Silver
Country of origin	China
On-board graphics card ID	0x116
Discrete graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Processor code	SR04S
Processor ARK ID	52220
Processor package size	37.5 x 37.5 xrPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	225 mm
Width	328 mm
Height	25.2 mm
Weight	1820 g
