Item Description Spare part number
7-mm hard drives
●
320 GB, 7200-rpm Self Encrypting 641674-001
● 320 GB, 7200-rpm 634862-001
●
250 GB, 7200-rpm 634861-001
Solid-state drive
● 128 GB 650401-001
(20) WWAN module (not available with Linux)
HP hs2340 HSPA+ Mobile Broadband Module 632155-001
HP un2430 EV-DO/HSPA Mobile Broadband Module 634400-001
(21) WLAN module
Broadcom 4313 802.11b/g/n 1x1 WiFi Adapter for use in Australia, Bangladesh, Bhutan,
Brunei, Cambodia, East Timor, Fiji, Hong Kong, India, Indonesia, Japan, Kiribati, Laos,
Malaysia, Maldives, Marshall Islands, Micronesia, Nauru, Nepal, New Zealand, Pakistan,
Palau, Papua New Guinea, the People's Republic of China, the Philippines, Samoa,
Singapore, Solomon Islands, South Korea, Sri Lanka, Taiwan, Thailand, Tonga, Tuvalu, and
Vietnam
593836-001
Broadcom 43224 802.11a/b/g/n WiFi Adapter for use in Antigua and Barbuda, Barbados,
Belize, Canada, the Cayman Islands, Guam, Puerto Rico, Trinidad and Tobago, the U.S.
Virgin Islands, and the United States
582564-001
Broadcom 43224 802.11a/b/g/n WiFi Adapter for use in Albania, Algeria, Angola, Argentina,
Australia, Austria, Bahrain, Bangladesh, Belarus, Belgium, Benin, Bolivia, Botswana, Brunei,
Bulgaria, Burkina Faso, Burundi, Cambodia, Cameroon, Cape Verde, the Central African
Republic, Chad, Chile, Colombia, the Congo, Costa Rica, Croatia, Cyprus, the Czech
Republic, Denmark, Djibouti, Dominica, Dominican Republic, Ecuador, Egypt, El Salvador,
Equitorial Guinea, Estonia, Finland, France, Gabon, Gambia, Germany, Ghana, Gibraltar,
Greece, Guinea, Guinea-Bissau, Hong Kong, Hungary, Iceland, India, Indonesia, Ireland,
Italy, the Ivory Coast, Japan, Grenada, Guatemala, Guyana, Honduras, Jordan, Kenya,
Kuwait, Kyrgyzstan, Laos, Latvia, Lebanon, Liberia, Liechtenstein, Lithuania, Luxembourg,
Madagascar, Malaysia, Mali, Mauritania, Mauritius, Mexico, Morocco, Mozambique, Namibia,
Nepal, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan,
Panama, Paraguay, the People's Republic of China, Peru, the Philippines, Poland, Portugal,
Puerto Rico, Qatar, Romania, Russia, Rwanda, Sao Tome and Principe, Saudi Arabia,
Senegal, Serbia and Montenegro, Sierra Leone, Singapore, Slovakia, Slovenia, South Africa,
South Korea, Spain, Sri Lanka, Suriname, Sweden, Switzerland, Taiwan, Tanzania,
Thailand, Togo, Tunisia, Turkey, Ukraine, the United Arab Emirates, the United Kingdom,
Uruguay, Venezuela, Vietnam, Yemen, and Zimbabwe
582564-002
Intel Centrino® Advanced N 6205 802.11a/b/g/n, 2x2 WiFi Adapter 631954-001
(22) Memory module (DDR3 PC3-10600 SDRAM, 1333 MHz, shared)
4096 MB 621568-001
2048 MB 621565-001
(23) Service access cover
NOTE: The service access cover is included in the Plastics Kit, spare part number
650395-001. See
Plastics Kit on page 22 for more Plastics Kit spare part information.
(24) Battery cover
NOTE: The battery cover is included in the Plastics Kit, spare part number 650395-001.
See
Plastics Kit on page 22 for more Plastics Kit spare part information.
20 Chapter 3 Illustrated parts catalog

HP ProBook 5330m Specifications

General

Bus type	DMI
Stepping	J1
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
System bus rate	5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-2300 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	21
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM67 Express
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	-
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Display diagonal	13.3 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Power supply type	AC/DC
Intel segment tagging	Enterprise
Operating temperature (T-T)	41 - 95 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Memory slots	1x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Memory slots (available)	0
Pointing device	Touchpad
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cable lock slot type	Kensington
Battery capacity	41 Wh
Battery life (max)	5.5 h
AC adapter power	65 W
Sustainability certificates	EPEAT Gold, ENERGY STAR
Product color	Black, Silver
Country of origin	China
On-board graphics card ID	0x116
Discrete graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Processor code	SR04S
Processor ARK ID	52220
Processor package size	37.5 x 37.5 xrPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	225 mm
Width	328 mm
Height	25.2 mm
Weight	1820 g
