Display components
Item Description Spare part number
(1) Display bezel
For use with computer models with a webcam 639469-001
For use with computer models without a webcam 639470-001
(2) Webcam module 641735-001
(3) Display hinges (Hinge kit includes left and right hinges, brackets, and covers) 639476-001
(4) Display cable kit includes LCD cable, LCD cable (system board to color mapping
board), LCD cable (color mapping board to panel)
For use with computer models with a webcam 639471-001
For use with computer models without a webcam 639472-001
(5) Display enclosure (LCD back cover assembly) 639467-001
30 Chapter 3 Illustrated parts catalog
