Bottom
NOTE: Your computer may look slightly different from the illustration in this section.
Item Component Description
(1) Vents (4) Enables airflow to cool internal components.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is
normal for the internal fan to cycle on and off during
routine operation.
(2) Battery release latch Releases the battery.
(3) Docking connector Connects an optional docking device.
(4) Service cover release latch Releases the service cover from the computer.
(5) Battery bay Holds the battery.
(6) Accessory battery connector Connects an optional accessory battery.
Bottom
