HP ProBook 6475b User Manual

System board
NOTE: The system board spare part kit includes replacement thermal material.
Description Spare part number
For use only on HP ProBook 6475b Notebook PC computer models:
For use on computer models equipped with the Windows 8 Professional operating system
and WWAN capability in all countries and regions except in the People's Republic of China
and the Ukraine
684341-601
For use on computer models equipped with the Windows 8 Standard operating system
and WWAN capability in all countries and regions except in the People's Republic of China
and the Ukraine
684341-501
For use on computer models equipped with the Windows 7 operating system and WWAN
capability in all countries and regions except in the People's Republic of China and the Ukraine
684341-001
For use on computer models equipped with the Windows 8 Professional operating system but
without WWAN capability in all countries and regions except in the People's Republic of China
and the Ukraine
684342-601
For use on computer models equipped with the Windows 8 Standard operating system but without
WWAN capability in all countries and regions except in the People's Republic of China
and the Ukraine
684342-501
For use on computer models equipped with the Windows 7 operating system but without WWAN
capability in all countries and regions except in the People's Republic of China and the Ukraine
684342-001
For use on computer models equipped with the Windows 7 operating system and WWAN
capability only in the People's Republic of China and the Ukraine
690036-001
For use on computer models equipped with the Windows 7 operating system but not WWAN
capability only in the People's Republic of China and the Ukraine
690037-001
For use only on HP ProBook 6470b Notebook PC computer models:
For use on computer models equipped with the Intel QM77 chipset, a graphics subsystem with
discrete memory, the Windows 8 Professional operating system, and WWAN capability in all
countries and regions except in the People's Republic of China and the Ukraine
686039-601
For use on computer models equipped with the Intel QM77 chipset, a graphics subsystem with
discrete memory, the Windows 8 Standard operating system, and WWAN capability in all
countries and regions except in the People's Republic of China and the Ukraine
686039-501
For use on computer models equipped with the Intel QM77 chipset, a graphics subsystem with
discrete memory, the Windows 7 operating system, and WWAN capability in all countries
and regions except in the People's Republic of China and the Ukraine
686039-001
For use on computer models equipped with the Intel QM77 chipset, a graphics subsystem with
UMA memory, the Windows 8 Professional operating system, and WWAN capability in all
countries and regions except in the People's Republic of China and the Ukraine
686037-601
For use on computer models equipped with the Intel QM77 chipset, a graphics subsystem with
UMA memory, the Windows 8 Standard operating system, and WWAN capability in all countries
and regions except in the People's Republic of China and the Ukraine
686037-501
For use on computer models equipped with the Intel QM77 chipset, a graphics subsystem with
UMA memory, the Windows 7 operating system, and WWAN capability in all countries
and regions except in the People's Republic of China and the Ukraine
686037-001
106 Chapter 4 Removal and replacement procedures

HP ProBook 6475b Specifications

General

Processor cache	1 MB
Processor cores	2
Processor family	AMD A6
Processor frequency	2.7 GHz
Processor cache type	L2
Processor manufacturer	AMD
Motherboard chipset	AMD AM70 FCH
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card model	AMD Radeon HD 7520G
On-board graphics card family	AMD Radeon HD 7000
LightScribe	-
Intel segment tagging	Enterprise
Audio system	SRS PS
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Pointing device	Touchpad
Recovery operating system	Windows 8 Pro
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Form factor	Clamshell
Product type	Laptop
Product color	Black
Country of origin	China
Battery capacity	55 Wh
Battery life (max)	8.5 h
Number of battery cells	6
AC adapter power	65 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	231 mm
Width	338 mm
Height	34 mm
Weight	2030 g
