Category Description
PC4, 2133-MHz, DDR4 SODIMMs (models with 8th generation Intel Core processors run at 2400 MHz)
Supports the following congurations:
● 32768 MB (16384 × 2; dual channel)
● 16384 MB (16384 × 1)
● 16384 MB (8192 × 2; dual channel)
● 12288 MB (8192 + 4096; dual channel)
● 8192 MB (8192 × 1)
● 8192 MB (4096 × 2; dual channel)
● 4096 MB (4096 × 1)
Primary M.2
storage
M.2 2280 SSD (NGFF)
● 512 GB, PCIe, NVMe, TLC (not available with Celeron)
● 256 GB, PCIe, NVMe, value (not available with Celeron)
● 256 GB, SATA, TLC
● 128 GB, SATA, TLC
Audio/Visual Audio controls
Integrated dual-array microphone
Integrated camera (720p HD) (supports Wide Dynamic Range [WDR])
IR camera (720p HD) (supports WDR)
Stereo speakers (2)
Headphone/microphone combo jack
Ethernet Realtek RTL8111HSH-CG 10/100/1000
S3/S4/S5 wake on LAN (AC mode and battery mode)
The following support S3/S4/S5 wake on LAN: embedded NIC
The following support S3/S4/S5 wake on LAN/HBMA (via out of band): HP Elite USB-C Dock G3, HP USB-C Dock
G4, HP USB-C Universal Dock, HP Thunderbolt Dock 120W G2, and HP USB-C Mini Dock
Wireless Integrated WLAN options by way of wireless module (select models only)
Support WiFi SAR (enabled in BIOS)
Supports HP Connection Optimizer with wi- load balancing
Supports the following wireless adapters via minicard connector:
● Realtek RTL8822BE 802.11AC 2x2 Wi-Fi + Bluetooth 4.2 Combination Adapter
● Intel Dual Band Wireless-AC 8265, 802.11ac, 2×2 Wi-Fi + Bluetooth 4.2 Combination Adapter (non-vPro)
Wireless Personal Area Network (PAN) Bluetooth
Bluetooth 4.2 supported using combo card
Integrated WWAN options by way of wireless module (select models only)
2 Chapter 1 Product description
