HP PROCURVE 2520 Planning And Implementation Guide

10-31
Planning and Implementation for the 5400zl/8200zl Switches
Configuration Examples
Planning and
Implementation for the
5400zl/8200zl Switches
In this configuration, EPS 2 of the Power Supply Shelf can be connected to
either EPS 1 or EPS 2 of either switch.
Figure 10-22.Connecting the EPS to two switches, one 5412zl and one 8212zl
To Power
Source
To Power Source
To P ow er
Source
To Po we r
Source
To Po we r
Source
EPS Cables
EPS 1
EPS 2
EPS 2
EPS 1
5412zl
8212zl

HP PROCURVE 2520 Specifications

General

Web Interface	Yes
CLI Support	Yes
IPv6 Support	Yes
Auto-MDIX	Yes
SNMP Support	Yes
Quality of Service (QoS)	Yes
VLAN Support	Yes
Jumbo Frame Support	Yes
