HP ProCurve 2810-24G

HP ProCurve Switch 2810 Series
2
Features and benefits
Industry-leading warranty
♦ For as long as you own the product, with next-business-day advance replacement (available in most countries). The following hardware products and their related series modules have a one-year
hardware warranty with extensions available: HP ProCurve Routing Switch 9300m Series, HP ProCurve Switch 8100fl Series, and HP ProCurve Network Access Controller 800. The following hardware
mobility products have a one-year hardware warranty with extensions available: HP ProCurve M111 Client Bridge, HP ProCurve MSM3xx-R Access Points, HP ProCurve MSM7xx Mobility and Access
Controllers, HP ProCurve RF Manager IDS/IPS Systems, HP ProCurve MSM Power Supplies, HP ProCurve 1-Port Power Injector, and HP ProCurve CNMS Appliances. Disk drives in the HP ProCurve
ONE Services zl Modules have a five-year hardware warranty. Standalone software, upgrades, or licenses may have a different warranty duration. For details, refer to the ProCurve Software License,
Warranty, and Support booklet at http://www.procurve.com/warranty.
Connectivity
• Dual-personality functionality: four 10/100/1000 ports or SFP
slots for optional fiber connectivity such as Gigabit-SX, -LX, -LH,
or 100-FX
Performance
• 35.7 Mpps at 64 bytes (HP ProCurve 2810-24G) and 71.4
Mpps at 64 bytes (HP ProCurve Switch 2810-48G): ten times
the bandwidth for low-latency throughput
Resiliency and high availability
• IEEE 802.3ad Link Aggregation Protocol (LACP) and
ProCurve trunking: support up to 24 trunks, each with up to 8
links (ports) per trunk
• IEEE 802.1s Multiple Spanning Tree: provides high link
availability in multiple VLAN environments by allowing multiple
spanning trees; provides legacy support for IEEE 802.1d and
IEEE 802.1w
• Optional redundant power supply: provides uninterrupted
power (provided by HP ProCurve 600 RPS/EPS)
Layer 2 switching
• VLAN support and tagging: supports the IEEE 802.1Q (4,094
VLAN IDs) and 256 VLANs simultaneously
• GARP VLAN Registration Protocol: allows automatic learning
and dynamic assignment of VLANs
• Jumbo packet support: supports up to 9,220-byte frame size to
improve performance of large data transfers
Security
• Port security: allows access only to specified MAC addresses,
which can be learned or specified by the administrator
NEW Protected ports: provides increased security by allowing
specified ports to be isolated from all other ports on the switch; the
protected port or ports can only communicate with the uplink or
shared resources
• MAC address lockout: prevents configured particular MAC
addresses from connecting to the network
• Multiple user authentication methods:
- IEEE 802.1X: industry-standard method of user authentication
using an IEEE 802.1X supplicant on the client in conjunction with
a RADIUS server
- Web-based authentication: similar to IEEE 802.1X, provides a
browser-based environment to authenticate clients that do not
support the IEEE 802.1X supplicant
- MAC-based authentication: client is authenticated with the
RADIUS server based on the client's MAC address
• Switch management logon security: can require either
RADIUS or TACACS+ authentication for secure switch CLI logon
• Multiple IEEE 802.1X users per port: provides authentication of
up to two IEEE 802.1X users per port; prevents user
"piggybacking" on another user's IEEE 802.1X authentication
• STP BPDU port protection: blocks Bridge Protocol Data Units
(BPDUs) on ports that do not require BPDUs, preventing forged
BPDU attacks
• Secure FTP: allows secure file transfer to/from the switch;
protects against unwanted file downloads or unauthorized copying
of switch configuration file
• RADIUS/TACACS+: eases switch management security
administration by using a password authentication server
• Source-port filtering: allows only specified ports to
communicate with each other
• Secure Shell (SSHv2): encrypts all transmitted data for secure,
remote command-line interface (CLI) access over IP networks
• Secure Sockets Layer (SSL): encrypts all HTTP traffic, allowing
secure access to the browser-based management GUI in the
switch
Convergence
• IP multicast snooping and data-driven IGMP: automatically
prevents flooding of IP multicast traffic
