HP ProCurve Switch 2810 Series
4
Specifications
HP ProCurve Switch 2810-24G (J9021A) HP ProCurve Switch 2810-48G (J9022A)
Ports
20 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T,
IEEE 802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T);
Media Type: Auto-MDIX; Duplex: 10Base-T/100Base-TX: half or full;
1000Base-T: full only
44 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T,
IEEE 802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T);
Media Type: Auto-MDIX; Duplex: 10Base-T/100Base-TX: half or full;
1000Base-T: full only
1 RJ-45 serial console port 1 RJ-45 serial console port
4 dual-personality ports; each port can be used as either an RJ-45
10/100/1000 port (IEEE 802.3 Type 10Base-T, IEEE 802.3u Type
100Base-TX, IEEE 802.3ab 1000Base-T Gigabit Ethernet) or an
open mini-GBIC slot (for use with mini-GBIC transceivers)
4 dual-personality ports; each port can be used as either an RJ-45
10/100/1000 port (IEEE 802.3 Type 10Base-T, IEEE 802.3u Type
100Base-TX, IEEE 802.3ab 1000Base-T Gigabit Ethernet) or an
open mini-GBIC slot (for use with mini-GBIC transceivers)
Physical characteristics
Dimensions
12.7(d) x 17.4(w) x 1.7(h) in. (32.26 x 44.2 x 4.32 cm) (1U height) 12.7(d) x 17.4(w) x 1.7(h) in. (32.26 x 44.2 x 4.32 cm) (1U height)
Weight
7.21 lb. (3.27 kg) 8.6 lb. (3.9 kg)
Memory and processor
Processor
MIPS @ 264 MHz, 16 MB flash, 64 MB SDRAM; packet buffer size:
0.75 MB
MIPS @ 264 MHz, 16 MB flash, 64 MB SDRAM; packet buffer size:
1.5 MB
Mounting
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet
(hardware included); horizontal surface mounting only
Mounts in an EIA-standard 19 in. telco rack or equipment cabinet
(hardware included); horizontal surface mounting only
Performance
Latency
< 5.6 µs (FIFO 64-byte packets) < 5.4 µs (FIFO 64-byte packets)
Throughput
up to 35.7 million pps up to 71.4 million pps
Switching capacity
48 Gbps 96 Gbps
MAC address table size
8000 entries 8000 entries
Environment
Operating temperature
32ºF to 113ºF (0ºC to 45ºC) 32ºF to 113ºF (0ºC to 45ºC)
Operating relative humidity
15% to 95% @ 104ºF (40ºC), non-condensing 15% to 95% @ 104ºF (40ºC), non-condensing
Non-operating/Storage temperature
-40ºF to 158ºF (-40ºC to 70ºC) -40ºF to 158ºF (-40ºC to 70ºC)
Non-operating/Storage relative humidity
15% to 95% @ 149ºF (65ºC), non-condensing 15% to 95% @ 149ºF (65ºC), non-condensing
Altitude
up to 10000 ft. (3 km) up to 10000 ft. (3 km)
Acoustic
Power: 40.3 dB Power: 40.5 dB
Electrical characteristics
Maximum heat dissipation
164 BTU/hr (173 kJ/hr) 341 BTU/hr (360 kJ/hr)
Voltage
100-127 / 200-240 VAC 100-127 / 200-240 VAC
Current
1.0 A 1.5 A
Power consumption
48 W 92 W
Frequency
50 / 60 Hz 50 / 60 Hz
Notes
Maximum power rating is the worst-case theoretical maximum power
number with fully loaded PoE, 100% traffic, all ports plugged in, and
all modules populated.
Maximum power rating is the worst-case theoretical maximum power
number with fully loaded PoE, 100% traffic, all ports plugged in, and
all modules populated.
Safety
