HP ProCurve 6200yl Series Advanced Traffic Management Guide

3-73
Multiple Instance Spanning-Tree Operation
Loop Protection
Figure 3-34 shows examples where loop protection can be used.
Figure 3-34. Examples of Loop Protection Enabled in Preference to STP
Unmanaged switch
(does not support STP)
Loop protection enabled ‘edge’
ports that connect to unmanaged
switches and/or authenticated
clients
Switch
STP Domain
Spanning tree enabled ports
Web authentication clients
802.1X authentication clients
