7-40
Configuring RADIUS Server Support for Switch Services
Configuring and Using Dynamic (RADIUS-Assigned) Access Control Lists
Access Policy Details:
COS Map: Indicates the 802.1p priority assigned by the RADIUS server for traffic
inbound on the port from an authenticated client. The field shows an eight-digit value
where all digits show the same, assigned 802.1p number. For example, if the assigned
802.1p value is 5, then this field shows
55555555. If an 802.1p priority has not been
assigned by the RADIUS server, this field shows Not Defined.
Untagged VLAN: VLAN ID (VID) of the untagged VLAN currently supporting the authen-
ticated connection.
Tagged VLANs: VLAN IDs (VIDs) of any tagged VLANs currently supporting the authen-
ticated connection.
RADIUS ACL List: Lists the explicit ACEs in the ACL assigned to the port for the
authenticated client. Includes the ACE “Hit Count” (matches) for ACEs configured with
the cnt option. (Refer to “ACE Syntax in RADIUS Servers” on page 7-26.) If a RADIUS
ACL for the authenticated client is not assigned to the port,
No Radius ACL List appears in
this field.
In Limit Kbps: Indicates the ingress rate-limit assigned by the RADIUS server to the port
for traffic inbound from the authenticated client. If there is no ingress rate-limit
assigned, then
Not Set appears in this field.
Out Limit Kbps: Indicates the egress rate-limit assigned by the RADIUS server to the port
for traffic outbound to the authenticated client. If there is no egress rate-limit assigned,
then
Not Set appears in this field.
