10-78

IPv4 Access Control Lists (ACLs)

Configuring Extended ACLs

[ precedence < 0 - 7 | precedence-name >]

This option causes the ACE to match packets with the

specified IP precedence value. Values can be entered as the

following IP precedence numbers or alphanumeric names:

0 or routine

1 “ priority

2 “ immediate

3 “ flash

4 “ flash-override

5 “ critical

6 “ internet (for internetwork control)

7 “ network (for network control)

Note: The precedence criteria described in this section are

applied in addition to

any other selection criteria config-

ured in the same ACE.

[ tos ]

This option can be used after the DA to cause the ACE to

match packets with the specified Type-of-Service (ToS) set-

ting. ToS values can be entered as the following numeric

settings or, in the case of 0, 2, 4, and 8, as alphanumeric

names:

0 or normal

2 “ max-reliability

4 “ max-throughput

8 “ minimize-delay

Note: The ToS criteria in this section are applied in addi-

tion to any other criteria configured in the same ACE.

[log]

Optional; generates an Event Log message if:

• The action is deny. (This option is not configurable for

Permit.)

• There is a match.

• ACL logging is enabled on the switch. (Refer to

“Enabling ACL Logging on the Switch” on page 10-114)
