13-67

Configuring Port-Based and User-Based Access Control (802.1X)

Displaying 802.1X Configuration, Statistics, and Counters

Figure 13-19. Example of Showing a VLAN with Ports Configured for Open VLAN Mode

HP Switch(config)# show vlan 1

Status and Counters - VLAN Information - VLAN 1

VLAN ID : 1

Name : DEFAULT_VLAN

Status : Static

Voice : No

Jumbo : No

Port Information Mode Unknown VLAN Status

---------------- -------- ------------ ----------

A1 Untagged Learn Up

A2 Untagged Learn Up

A3 Untagged Learn Up

A4 Untagged Learn Up

B2 Untagged Learn Up

B4 Untagged Learn Up

B23 Untagged Learn Up

B24 Untagged Learn Up

Overriden Port VLAN configuration

Port Mode

---- ----------

B1 Untagged

B3 Untagged

Note that ports B1 and B3 are

not in the upper listing, but are

included under “Overridden

Port VLAN configuration”. This

shows that static, untagged

VLAN memberships on ports B1

and B3 have been overridden

by temporary assignment to the

authorized or unauthorized

VLAN. Using the show port-

access authenticator < port-

list > command shown in figure

13-18 provides details.
