HP ProCurve zl Series User Manual

4-3
Planning and Implementation for the Series 5400zl Switch
Planning Your PoE Configuration
Planning and
Implementation for the
Series 5400zl Switch
Table 4-2. 5412zl Power Configurations
1
The redundancy values shown here assume all the power supply bays in the
switch are filled. Always fill internal bays before adding an external supply to
ensure redundancy of system power.
Switch Model 5412zl Power Supply Model Redundancy
System and PoE
J8712A
(110 or 220 volts)
J8713A
(220 volts only)
Standard PoE Power 20None
3 0 N+1 - Up to 546 W of
PoE power
4 0 Full - Up to 546 W of
PoE power
High PoE Power
(Optimum)
02None
0 3 N+1 - Up to 1800 W of
PoE power
0 4 Full - Up to 1800 W of
PoE power
Or
N+1 - up to 2700 W of
PoE power
Mixed PoE Power
(Not Recommended)
21System only
See
page 4-18
12System only
See
page 4-19
22System only
See
page 4-20
Power Supply Shelf
Standard PoE Power
10No System
Redundancy - up to 273
W of PoE power
1
20No System
Redundancy - up to 546
W of PoE power
1
Power Supply Shelf
High PoE Power
(Optimum)
01No System
Redundancy - up to 900
W of PoE power
1
02No System
Redundancy - up to
1800 W of PoE power
1
Power Supply Shelf
Mixed PoE Power
(Not Recommended)
11No System
Redundancy - up to
1173 W of PoE power
1
