Planning Your PoE Configuration
Planning and
Implementation for the
Series 5400zl Switch
Figure 4-16. Connecting the EPS to one 5412zl switch
Even thought either EPS port on the Power Supply Shelf can be connected to
either EPS port on the switch, to avoid confusion, it is recommended that
EPS 1 of the Power Supply Shelf be connected to EPS 1 of the switch.
To Power
Source
EPS Cables
To Power
Source
5412zl
To Power
Source
To P o we r
Source
EPS 2
EPS 1
EPS 2
EPS 1
